Water Treatment Equipment

Water equipment for secondary water supply, sewage lifting, prefabricated pump stations, and domestic wastewater treatment. Select the system from the required flow, head, water quality, site conditions, power supply, and control requirements.

BUILDING WATER SUPPLY

Water Booster Pumping Systems

MODEL YHGW

Non-Negative Pressure Booster Pump Sets

YHGW tank-type non-negative-pressure water supply equipment connects directly to the municipal network and boosts water on the residual mains pressure through a sealed pressurized steady-flow compensation tank, so no negative pressure is created and the municipal network is never disturbed. Fully automatic stacked-pressure dispatch, under-pressure compensation and a three-level anti-negative-pressure control (combined inlet/outlet pressure monitoring, peak compensation and a vacuum suppression device) protect both the mains and supply stability. Configured per project by number of pumps, head and flow.

View product →

MODEL YHB

Variable Speed Booster Pump Sets

YHB variable-frequency booster water supply equipment pressurizes water drawn from a clean storage tank or inlet main and keeps outlet pressure constant as demand changes. Pump speed and the number of running pumps follow real-time demand, saving energy and extending pump life. Factory-built and tested where included in the agreed scope, the YHB skid is configured per project by number of pumps, head and flow, and can be extended with IoT remote monitoring.

View product →

MODEL YHXW

Water Tank for Non-Negative Pressure Water Booster Pumping Set

YHXW box-type non-negative-pressure water supply equipment integrates a hygienic buffer water chamber and a variable-frequency boosting skid in one compact unit. Connected directly to the municipal network, it boosts water on residual mains pressure while a three-level anti-negative-pressure control loop keeps the municipal supply safe, and the integrated buffer volume helps to smooth peak demand. Factory-built and tested where included in the agreed scope; configured per project by number of pumps, head and flow.

View product →

DRAINAGE & SEWAGE LIFTING

Integrated Prefabricated Pump Stations

YHWT-A Integrated Prefabricated Sewage Pump Station

EQUIPMENT SERIES

Integrated Prefabricated Pump Station

YHWT-A is a buried GRP sewage lifting station with project-selected submersible sewage pumps, automatic couplings, internal pipework, level instruments, screening and controls. Flow, total head, pump arrangement, shaft dimensions and installation requirements are confirmed for each project.

View product →

DOMESTIC WASTEWATER TREATMENT

Integrated Sewage Treatment Systems

MODEL YHWJ-A

Carbon Steel Wastewater Treatment System

Integrated domestic wastewater treatment equipment with a Q235 carbon-steel shell and project-specific corrosion protection. Treatment capacity, process configuration and buried installation requirements are defined around the wastewater, effluent target and site conditions.

View product →

Fiberglass Integrated Domestic Wastewater Treatment System YHWJ-B

MODEL YHWJ-B

Fiberglass Wastewater Treatment System

Integrated domestic wastewater treatment equipment with a fiberglass / GRP shell for decentralized projects. Treatment capacity, process configuration and installation requirements are defined around your wastewater, effluent targets and site conditions.

View product →

PRODUCT SELECTION SUPPORT

Need help selecting a configuration?

Send your specifications, operating conditions, or project requirements for product-selection support.

Contact Yuanheng →
